Tiger Motor MN2212 920kv v2.0

  • $46.99
  • Fast Two-Day Shipping

Earn 4699 DronePoints

In Stock


Guaranteed Delivery - Delivered from to

*Get Fast & Free Two-Day Shipping By Ordering $99

Details

Designed specifically for multi-rotors, the Navigator Series from Tiger Motors includes some of the best multi-rotor motors available today.

The Multi-hole design allow almost any type of prop to be mounted to the motor.

Specifications:

KV................................................................................................................920
Configu ration.......................................................................................9N12P
Stator Diameter.....................................................................................22mm
Stator Length.........................................................................................13mm
Shaft Diameter.........................................................................................4mm
Motor Dimensions(Dia.*Len).............................................Φ27.5×26.5mm
Weight (g)...................................................................................................54g
ldle current(10)@10v(A).........................................................................0.4A
No.of Cells(Lipo)......................................................................................2-4S
Max Continuous current(A)180S............................................................15A
Max Continuous Power(W)180S.........................................................220W
Max. efficiency current................................................................(2-7A)>82%
internal resistance................................................................................142mΩ

920kv table
